NGP Commercial Weatherstrips

Fast Shipping

Lowest Prices

Instant Pricing

Lowest Prices
Shop Hardware

National Guard Products Weatherstrips Features

POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C
Complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes (some ratings vary as noted).

CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B
Complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes (some ratings vary as noted).

NGP-EDGE® SEALING SYSTEM
Certified by UL to ANSI/UL10C Category ‘G’; required for Category B wood fire doors to meet positive pressure requirements complying with IBC, and NFPA 252. See individual products for maximum door size and ratings.

SMOKE & DRAFT CONTROL GASKETING
Certified by UL to ANSI/UL10C and ANSI/UL 1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes (some ratings vary as noted).

ACOUSTICAL TESTED
ASTM E90 Standard Test Method for Laboratory Measurement of Airborne Sound Transmission Loss of Building Partitions and Elements, and ASTM E2235 Standard Test Method for Determination of Decay Rates for use in Sound Insulation Test Methods. Refer to information on pages G4 and G5 for test result data.

AIR INFILTRATION TESTED
ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.

MEETS BUY AMERICAN ACT REQUIREMENTS
Click Here to see all Weatherstrip Features

Materials

Metal retainers for gasketing are Aluminum Alloy 6063, T5 temper, unless noted.

Architectural Bronze gasketing is Alloy CDA 385 (Copper Alloy No. C38500), Architectural Bronze.

Stainless steel gasketing is Type 304; known for its excellent corrosion resistance, high tensile strength and resistance to oxidation.

NGP utilizes a variety of gasketing materials including Vinyl, Neoprene, Silicone, Nylon Brush, ThermoPlastic Elastomers (TPE), Thermo-Plastic Vulcanizates (TPV), Polypropylene Pile, Ethylene-Propylene-Diene-Monomer (EPDM), Polyurethane, and Intumescent Fire Seals. Product Illustrations indicate the Gasketing material. Properties of many primary gasket materials are listed on the perimeter seal catalog pages.

Adhesive mounted gasketing utilizes a pressure sensitive modified acrylic adhesive protected by a release liner. Once installed it provides a permanent bond in exterior or interior locations. End use temperature range is -30°F up to 250°F. Shelf life of adhesive prior to installation is one year when stored at 75°F and 50% relative humidity or less.

Finishes

Aluminum
Mill Finish
Anodized Aluminum
Dark Bronze
Polished
Gold
Powder Coated Colors
Architectural Bronze
Satin Finish
Dark Bronze Oil Rubbed
Polished
Stainless Steel
Brushed (#4)
